API Oilfield Downhole Tools 101'' Bottom Plug Cementing

Brand Name : Puyang Zhongshi Group

Model Number : 4 1/2"~20"

Certification : API,ISO,QHSE

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, MoneyGram

Delivery Time : depends on quantity

Packaging Details : Wooden Box

Type : Non-rotating

Material : Rubber

Color : as required

Core Inside : Aluminum inside

Temperature : -30℃ to 150℃

Working Pressure : ≥15MP

Contact Now

API Oilfield Downhole Tools Cementing Bottom Plug

The Top Cementing Plug, the fins and tail section provide positive wiping action. Fins also serve as a seal while cementing. The core of the bottom plug also made of special materials such as Plastic, Aluminium or Phenolic depending on the application and well conditions. A rubber diaphragm at the top of the plug ruptures after the plug is seated allowing cement to flow through

API Oilfield Downhole Tools Cementing Bottom Plug Features

  • These plugs are completely PDC drillable.

  • Temperature with Aluminum core is up to 200 degree Fahrenheit.

  • The top plug has a solid body that provides positive indication of contact with the landing collar

  • and bottom plug through an increase in pump pressure.

  • Plug can be ordered for higher operating temperature and operation in either synthetic or mud fluids

API Oilfield Downhole Tools Cementing Bottom Plug Specification
Inch size MM O.D(mm) Labial ministry diameter(mm) Main body diameter(mm) Bore Dia
(mm)		 Length
(mm)
Rubber Polyurethane Rubber Polyurethane Rubber Polyurethane
101 101~104 96~99 94~97 89~92 77~80 72~75 ≥40 100~190
114 114~116 109~111 108~110 102~105 80~83 75~78
127 127~130 122~125 120~123 115~118 90~93 87~90 ≥50 120~210
140 140~145 135~140 130~ 135 125~130 100~103 97~100
178 178~183 173~175 168~173 163~168 130~135 125~130 ≥70 150~240
194 194~201 189~196 182~189 177~184 145~150 140~145
219 219~223 214~218 210~214 205~209 168~173 163~168 180~260
244 244~249 239~243 234~239 229~234 192~197 187~192
273 273~279 268~273 262~268 257~263 210~214 205~209 220~300
298 298~305 293~297 286~293 281~288 236~243 231~238
340 340~348 335~343 326~334 321~329 264~272 259~267 260~350
508 508~519 503~514 490~501 485~496 424~435 419~430 ≥100 360~450

API Oilfield Downhole Tools 101'' Bottom Plug Cementing
